Top Supplier of Automatic Deflashing Deburring Tool for Rubber and Plastic Parts Model PG-120T
Cryogenic deflashing machines are known for its precise quality de-flashed parts with up to 95% performance output without affecting the final part dimension and shape from small O-rings to big molded parts.
These Machines serve the need for Rubber, Metal-Rubber parts, small precision plastic parts and small die-casting parts like Zinc and Managanesium alloy.
rubber deflashing machine, Rubber Deflashing machine supplier in China,Oring Deflasing machine supplier in China,Deflashing machine supplier in China,Liquid Nitrogen Cryogenic Deflashing machine supplier in China
PRODUCT DESCRIPTION
PROCESSING PRINCIPLE
With the decrease of the temperature, rubber/plastic parts enter into hardened, brittle, and crystallized process, its flexibility is gradually lost. It is easily broken by external force when it is under brittle temperature. Flash of the molded products is generally much thinner than finished product itself, it become brittle earlier than product in the low temperature. Cryogenic deflashing machine applies this principle, works in the time range when flash is brittle while products still keeps its flexibility, hit the flashes by high speed projected special plastic media, clear out the brittle burr. The flashes can be easily removed, and the product not be damaged.
Product Feature
FUNCTIONS of cryogenic trimming machine
Our machine is widely used in removing the flashed of small rubber and plastic parts like O-rings, gaskets and other molded parts.
With the cryogenic processing technology, the flashes are firstly freeze and then shot down the high-speed projection media (Polycarbonate blast). The surface quality of molded rubber and plastic rubber parts can be improved greatly.
Product Specification / Models
APPLICATIONS of cryogenic deflashing machine
A. O rings, irregular rubber parts with different material and sizes.
B. Micro electronic product parts
C. Precision elastomeric parts
D. Precision injection moulding plastic parts
E. R & D part runs
F. Die casting products, like zinc aluminum, magnesium alloy
FEATURES of cryogenic deburring machine
High efficiency: The machine can replace about 60-80 worker to removing the flashes.
High precision: It can remove small and hardened flashes which cannot be removed by handworkers and improve precision of the products.
Low cost: It also has a feature of lower cost comparing with processing the parts by handworkers.
SPECIFICATIONS
PG-120T
Size:1200mm*1250mm*2200mm
Weight:1000kg
Power supply: AC380V 50HZ 3Ph
Electrical capacity: 8kw
Temperature: -130C--50C
Pressure:0.5-0.7Mpa
Barrel capacity:40L
Wheel speed: 3000rpm-7000rpm
Cooling media: liquid nitrogen
Material: SUS304
Weight |
1000kg |
Voltage |
As your local need,general is 380V, 3ph, |
Dimension(l*w*h) |
1100*1200*2000mm |
Power(w) |
6/7/8/9KW |
Condition |
New |
Type |
Rubber Cutting Machine, PLC, Deflashing machine, Vertical, Trimming equipment |
Application |
separate product from edage, Rubber complicated, use a cryogenic deflashing machine for rubber parts, Vacuum pump, Rubber Industry |
Capacity |
120L |
Control |
automatic control |
Max temperature |
-130℃ |
Dimensions |
1100*1200*2000rpm |
Service |
OEM / ODM |
Freeze source |
Liquid nitrogen |
Roller speed |
0-25 RPM |
Wheel Speed |
0-7000/7200rpm |
Product name |
Cryogenic deflashing machine |
Usage |
Cryogenic deflashing machine for deflashing rubber parts |
Advantages |
High production efficiency,High Precision, Lower Cost |
After-sales service provided |
Online support, Field installation, commissioning and training, Video technical support, Field maintenance and repair service |
Warranty |
1 Year, One Year
|
